Product Details:
Place of Origin: CHINA
Brand Name: ZG
Certification: CE
Model Number: MS
Payment & Shipping Terms:
Minimum Order Quantity: 1 piece
Price: Negotiation
Packaging Details: Strong wooden box for global shipping
Delivery Time: 5-8 working days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 10000 Pieces per month

FUSED MONOCLINIC ZIRCONIA POWDER, FUSED CALCIUM STABILIZED ZIRCONIA, FUSED MAGNESIA STABILIZED ZIRCONIA

Description
Application: Refractories, Kiln Furniture, Investment Cast, Ceramic Pigments, Structural Ceramics, Slide Gate, Nozzles, AZS Material: Zirconia
Color: White, Customized Shape: Customized
High Light:

refractory Fused Monoclinic Zirconia

,

D50 Zirconium Dioxide Powder

,

Fused Monoclinic Zirconia D50



Fused Monoclinic Zirconia Powder



Fused Monoclinic Zirconia Powder used in refractory, ceramic pigment, zirconium rod, automotive brake additives

We supply a full series of Fused Zirconia products, product includes Fused Monoclinic Zirconia, Fused Calcium Stabilized Zirconia, Fused Magnesia Stabilized Zirconia and Fused Yttria Stabilized Zirconia.

Fused Zirconia is produced in electric arc furnace at temperatures in excess of 2700C. Zirconia has excellent thermal shock resistance and is very thermally stable to high temperatures, has low thermal conductivity, and is chemistry insert. Zirconia is also not wetted by many metals and glasses and is therefore an excellent contact material in the existence of slags. Fused Zirconia is used in steel and glass contact refractories, investment casting as shell building material, as wear resistant coatings, thermal barrier coatings, and other applications that require high temperature, and frequent thermal cycling.









Applications of Fused Zirconia Powders:

  • Zirconium silicate based ceramic pigments, used in tiles, glazes, sanitary ware
  • Refractory ceramics, molten metal filters
  • Glass and gemstones composition
  • Electronic ceramics: PZT, multi-layer ceramic capacitor (MLCC), Dielectric components
  • Thermal spray powders (TSP), EBPVD ingots for thermal barrier coatings (TBC)
  • Structural ceramics for the industry: valve components, wear & abrasion resistant components, milling medias,bearings, cutting tools, …
  • Ferrules and sleeves for optical fiber connectors
  • Consumer and decorative ceramics: watches, knives, mobile phone part,…
  • Dental ceramics
  • Ionic conductive ceramics: gaz sensors, solid oxide fuel celles (SOFC)





Fused Monoclinic Zirconia Powder:



Code

Chemical Composition(%)

Size D50

(μm)

ZrO2+HfO2

SiO2

Al2O3

Fe2O3

TiO2

ZF-M-12

≥99

≤0.30

≤0.10

≤0.04

≤0.13

Hollow Balls or in

customized powder



Main applications:


Ceramic pigment, welding rod, brake additive, Zirconia nozzle, sliding plate,etc.

Fused Calcium Stabilized Zirconia:



Code

Chemical Composition ( % )

Stabilized

rate ( % )

True densiy

(g/cm3 )

Size

ZrO2+HfO2

Al2O3

SiO2

CaO

Fe2O3

TiO2

ZF-C-94

≥94

≤0.60

≤0.60

3.5-4.2

<0.15

<0.30

> 95

>5.6

Hollow ball, Dense

grain or powder according

to

customer’s

requirement



Main applications:



Refractory setter for electro-ceramic production, sizing nozzle, sliding plate, submerged nozzle, zirconia hollow ball products, zirconia furnace furniture,etc.





Fused Magnesia Stabilized Zirconia:



Code Chemical Composition ( % ) Stabilized rate ( % ) True density (g/cm3 ) Size
ZrO2 Al2O3 SiO2 MgO Y2O3 Fe2O3 TiO2
ZF-M-A ≥ 95 ≤0.1 ≤0.2 2.5-3.5 ≤0.3 ≤0.10 ≤0.1 70-85 >5.7 customized
ZF-M-B ≥ 94 ≤0.4 ≤0.4 2.5-3.5 ≤0.5 ≤ 0.15 ≤0.2 50-70 >5.6 customized





Main applications:



Mainly used in special zirconia ceramic products, such as grinding body, sizing nozzle, refractory setter for electro-ceramic production, ceramic structure components,etc.


Fused Yttria Stabilized Zirconia:



Code Chemical Composition(%) Stabalisation Rate
( % )
True Density
(g/cm3)
Size
ZrO2 Al2O3 SiO2 CaO Y2O3 Fe2O3 TiO2
ZF-Y-5-B >93 <0.3 <0.4 <0.2 4.8-5.5 <0.1 <0.2 >50 >5.8

Hollow bubble, Dense grain

or powder according to

customer’s requirement



ZF-Y-7-a ≥90 ≤0.1 ≤0.2 ≤0.2 7-8.5 ≤0.1 ≤0.1 75-85 >6.1
ZF-Y-7-b ≥91 ≤0.1 ≤0.1 ≤0.1 7-8.5 ≤0.1 ≤0.1 >98 >6.1
ZF-Y-7-c ≥90 ≤0.3 ≤0.4 ≤0.2 7-8.5 ≤0.1 ≤0.2 75-85 >6.0
ZF-Y-7-d ≥90 ≤0.1 ≤0.2 <0.5 7-8.5 ≤0.1 ≤0.1 >95 >6.0
ZF-Y-9 >89 <0.2 <0.4 <0.2 8.8-9.8 <0.1 <0.2 >85 >6.1
ZF-Y-13-A >84 <0.1 <0.1 <0.1 13-14 <0.05 <0.05 >95 >6.2
ZF-Y-13-B >84 <0.2 <0.2 <0.2 13-14 <0.1 <0.2 >95 >6.2



Main applications:



Mainly used to make zirconia refractories, filling material for induction furnace insulation layer; titanium alloy investment casting coating material, zirconia ceramic products, aluminum plate surface spraying, plasma spraying, oxygen permeable membrane ceramic ring, etc.
