Product Details:
|
| Features: | High Hardness; High Corrosion Resistance; Low Density; Stability In A Wide Range Of Temperatures; Precision Machining Capability. | Material: | Alumina |
|---|---|---|---|
| Size: | Customized | Color: | White |
| Highlight: | Approximate Spherical Alpha Alumina,Alpha Alumina Powder D50 9um,20um Alpha Alumina Powder |
||
Approximate Spherical Alpha Alumina For Heat Conduction
●Specification
| SW-2 | SW-5 | SW-8 | SW-15 | SW-20 | ||
| Al2O3 | % | ≥99.5 | ≥99.5 | ≥99.5 | ≥99.5 | ≥99.5 |
| SiO2 | ≤0.10 | ≤0.08 | ≤0.08 | ≤0.08 | ≤0.08 | |
| Fe2O3 | ≤0.03 | ≤0.03 | ≤0.03 | ≤0.03 | ≤0.03 | |
| Na2O | ≤0.10 | ≤0.10 | ≤0.10 | ≤0.10 | ≤0.10 | |
| LOI | ≤0.10 | ≤0.10 | ≤0.10 | ≤0.10 | ≤0.10 | |
| H2O | ≤0.10 | ≤0.10 | ≤0.10 | ≤0.10 | ≤0.10 | |
| D50 | μm | 3.0±0.5 | 6.5±0.5 | 9.0±2.0 | 13.0±2.0 | 20.0±2.0 |
| Density | g/cm3 | 0.6±0.2 | 0.9±0.2 | 1.0±0.2 | 1.0±0.2 | 1.2±0.2 |
| Oil Absorption | % | ≤45 | ≤40 | ≤35 | ≤30 | ≤30 |
Application:
high thermal conductivity gel, high thermal conductivity gasket, electronic packaging and other industries.
Features:
