Product Details:
|
| Shape: | Round, Square, Rectangular Or Other Customized Shapes | Application: | Diamond Tools |
|---|---|---|---|
| Feature: | High Strength, High Hardness And High Wearing Property Of Diamond Layer As Well As Good Self-sharpening | Type: | 30/40 |
| Highlight: | Synthetic Diamond Micron Powde,Resin Bond Diamond Micron Powde,Metal Bond Synthetic Diamond Powder |
||
SYNTHETIC DIAMOND MICRON POWDER,RESIN BOND SYNTHETIC DIAMOND POWDER,METAL BOND SYNTHETIC DIAMOND POWDER
1. SYNTHETIC DIAMOND MICRON POWDER
Synthetic diamond micro-powder is a new type of ultrafine super-hard materials (finer than 320#). It is used extensively in the fields of machinery, electronics, aviation and space flight, optical instrument, glass, ceramic, oil, geological and industry. It is an ideal material for grinding and polishing horniness alloy and optical glass. Generally, sizes from W 0-0.5 to W 6-12 is suitable for polishing, sizes from W5-10 to W 22-36 is used for grinding, sizes of W 12-22 and up is used for fine grinding.
Diamond Micron Powders undergo the second acid-base treatment and vacuum treatment. As a result, both the purity and the grain size distribution have reached extremely high standard of the industry. With a full range of grain sizes, the 20 standard micron sizes are listed in following Chart:
| 0-0.3 | 0.5-1 | 0.5-2 | 1-2 | 1-3 | 2-4 | 3-5 | 4-6 | 4-8 | 5-10 |
| 6-12 | 8-12 | 10-20 | 15-25 | 20-30 | 25-35 | 30-40 | 40-50 | 40-60 | 50-60 |
Note: Other sizes available per requirement, please contact us for more information
2. RESIN BOND SYNTHETIC DIAMOND POWDER
Resin Bond Diamond consists of brittle particles which render it continuous, highly efficient cutting ability. It is widely used in processing tungsten carbide, ceramics, glass, and polycrystalline cutting tools. Resin bond diamond powder has permanent renewal of sharp cutting edges, and excellent retention of ability with bonds, ensure provide perfect finish and integrity surface.
| Grade | Characteristics |
| S-RVD | Light green colored, medium friability. Density: 3.52 gms/cm³ |
| S-RVD2 | Black colored, friability. Density: 3.52 gms/cm³ |
| S-RVD3 | Green colored, more friable than B-RVD2. Density: 3.52 gms/cm³ |
Resin Bond Synthetic Diamond Powder Available Meshes:
| 60/80 | 80/100 | 100/120 | 120/140 | 140/170 | 170/200 |
| 200/230 | 230/270 | 270/325 | 325/400 | 400/500 |
3. METAL BOND SYNTHETIC DIAMOND POWDER
| Grade | Characteristics | Applications | Available Mesh |
| RVD | Irregular shape with low impact strength. | resin or ceramic bond wheels for grinding or polishing glass, stone and hard metal. | 40/50, 50/60, 60/70, 70/80, 80/100, 100/120, 120/140, 140/170, 170/200, 200/230, 230/270, 270/325, 325/400 |
|
MBD4
|
Crystals are block sharpen with rough surface. | resin or metal bond wheels and electroplated products for grinding hard metal and non-metal materials. | 40/50, 50/60, 60/70, 70/80, 80/100, 100/120, 120/140, 140/170, 170/200, 200/230, 230/270, 270/325, 325/400 |
|
MBD6
|
Better crystal. | cutting & grinding stone and concrete | 40/50, 50/60, 60/70, 70/80, 80/100, 100/120 |
|
MBD12
|
Perfect crystal with middle strength. | cutting tools for marble and metal bonded tools, such as grinding wheels. | 40/50, 50/60, 60/70, 70/80, 80/100, 100/120 |
|
SMD
|
Perfect crystal with smooth surface and middle strength. | cutting and profiled tools for average granite & ceramic. | 40/45, 45/50, 50/60, 60/70, 70/80 |
|
SMD25
|
Perfect crystal with high strength. |
cutting tools for granite, such as saw blade, disc, as well as tools for ceramics and wheels for squaring, beveling and edge polishing | 40/45, 45/50, 50/60, 60/70, 70/80 |
|
SMD30
|
Very high strength and good diaphaneity. | cutting tools for hard materials, such as single and multiple saw blades, disc and wire | 40/45, 45/50, 50/60, 60/70, 70/80 |
|
SMD35
|
Most perfect crystal with very high strength and diaphaneity. | dressing tools, the cutting tools for very hard materials, stone, such as saw blade ,disc, drill bit | 40/45, 45/50, 50/60, 60/70, 70/80 |
