Macor Machinable Glass Ceramic

Macor Machinable Glass Ceramic
Macor Machinable Glass Ceramic Macor Machinable Glass Ceramic

Large Image :  Macor Machinable Glass Ceramic

Product Details:
Place of Origin: China
Brand Name: ZG
Certification: CE
Model Number: MS
Payment & Shipping Terms:
Minimum Order Quantity: 1 PC
Price: 10USD/PC
Packaging Details: Strong wooden box for Global shipping
Delivery Time: 5-8 work days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 1000 PCS
Contact Now

Macor Machinable Glass Ceramic

Description
Highlight:

Macor machinable glass ceramic

,

Machinable ceramic with high temperature resistance

,

Glass ceramic for precision machining

 Macor Machinable Glass Ceramic



Macor machinable glass ceramic has the versatility of a high performance polymer, the machinability of a metal, and the performance of an advanced technical ceramic. It is a hybrid glass-ceramic and offers a unique combination of properties from both families of materials. Macor is an excellent electrical and thermal insulator, and offers good performance in high temperature, vacuum, and corrosive environments.

One of the main advantages of Macor is that it can be machined with conventional metalworking tools. This allows for significantly faster turnarounds and substantially lower production costs when compared with other technical ceramics, making it an excellent material for both prototyping and medium-volume production runs.





Advantages

  • Can be machined with normal metalworking tools
  • Strong and rigid; unlike high temperature plastics, Macor will not creep or deform
  • Low thermal conductivity; useful high temperature insulator
  • Electric insulator, especially at high temperatures
  • Excellent with high voltages and a broad spectrum of frequencies
  • Does not require firing after machining
  • Continuous use temperature of 800°C; Peak temperature of 1000°C
  • Zero porosity
  • Won’t outgas in vacuum environment
  • Very tight machining tolerances of up to 0.0005in (0.013mm)
  • Excellent dimensional stability in a variety of environments (heat, radiation, etc.)
  • Radiation resistant
  • Coefficient of thermal expansion readily matches most metals and sealing glasses



Applications

  • Precision coil formers (high precision and dimensionally stable)
  • High voltage insulators (smooth surface finish and unaffected by arcing)
  • Spacers, cavities and reflectors in laser assemblies (precision finish and heat resistant)
  • Thermal breaks in high temperature processing equipment
  • Coil supports and vacuum feed-throughs (vacuum stable and hermetically sealable)
  • Retaining rings on hinges, windows and doors of NASA’s Space Shuttle
  • Supports and components in several satellite borne systems (thermally and electronically insulating)
  • Fixtures and reference blocks in power generation units (dimensionally unaffected by irradiation)

Mechanical Properties

Macor machinable glass ceramic is strong and rigid. It has zero porosity and can be polished to a smoothness of 0.5µin.

Thermal Properties

Macor will not creep or deform like high temperature plastics. It has low thermal conductivity, which makes it useful as a high temperature insulator. Macor has excellent dimensional stability in a variety of environments (heat, radiation, etc.). It’s coefficient of thermal expansion readily matches most metals and sealing glasses.



Electrical Properties

Macor machinable glass ceramic is a good electric insulator, especially at high temperatures. It works excellent with high voltages and a broad spectrum of frequencies. It is also radiation resistant.

Tag:

White Macor Machinable Glass Ceramic,

2.58g/Cm3 macor glass ceramic,

488 MPa macor glass ceramic
