Product Details:
|
| Application: | Melting Crucibles, Stoppers, Tundishes, Sliding Plates, And Other Peripheral Components As Well As In Carbon Brushes For Rolling And Winding Machines And A Variety Of Other Processes | Shape: | Plates, Strips, Pipes, Rods, Wire, And Contoured Shapes |
|---|---|---|---|
| Product Type: | Graphite Dies | ||
| High Light: | Porous Graphite Mold 45mm Grain,Glass Industry Porous Graphite Dies,45mm Grain Size Graphite Dies |
||
Achieving the best results when producing household glass decisively comes down to excellent material quality of the components used in the production process. With our porous hard carbon material FU 4960, we offer the perfect material for your raw cylinders. Our material combines a high capacity for water retention, excellent gas permeability, outstanding thermal resistance and a very long service life.
Material Technical Specifications:
|
Type |
Max Grain size mm |
Bulk Density g/cc |
Specific resistivity μΩ.m |
Flexural Strength Mpa |
Compressive Strength Mpa |
C.T.E(100-600℃) |
Ash % |
|
ZGB-I |
0.8 |
≥1.68 |
≤9.5 |
≥13.0 |
≥28.0 |
≤2.8 |
≤0.3 |
|
ZGB-II |
0.58 |
≥1.72 |
≤8.5 |
≥15.0 |
≥32.0 |
≤2.4 |
≤0.3 |
|
ZGL-0 |
2 |
≥1.58 |
≤11.5 |
≥7.0 |
≥18.0 |
≤3.0 |
≤0.3 |
|
ZGL-I |
2 |
≥1.68 |
≤9.0 |
≥13.0 |
≥28.0 |
≤2.7 |
≤0.3 |
|
ZGDJY-C1 |
22 |
≥1.78 |
≤10 |
≥38.0 |
≥65.0 |
≤3.9 |
≤0.07(Normal) |
|
ZGDJY-Y3 |
22 |
≥1.86 |
≤13.0 |
≥40.0 |
≥80.0 |
≤3.9 |
≤0.07(Normal) |
|
ZGDJY-W5 |
22 |
≥1.85 |
≤12.0 |
≥45.0 |
≥90.0 |
≤4.3 |
≤0.07(Normal) |
|
MY-III |
45 |
≥1.83 |
≤10.0 |
≥38.0 |
≥80.0 |
≤3.5 |
≤0.1 |
|
MY-IV |
45 |
≥1.88 |
≤9.0 |
≥42.0 |
≥90.0 |
≤3.8 |
≤0.07 |
|
If you can not find the material which you need, please kindly contact us ,we will choose apporpiate materialaccording to customer's application (working condition)based on rich experiences in graphite application |
|||||||
You benefit from these advantages:
Perfectly matched graphite-based material
Porous nature means high capacity for water retention
Excellent gas permeability
Outstanding thermal resistance and long service life
Features:
Excellent thermal durability
Good thermal conductivity
Resists wetting by molten metals
Complex shapes can be processed
Reduces metal sleeve weight
Various surface modifications and treatments enable a variety of applications
Due to its ability to resist wetting by molten metals, graphite is used as a mold material for strip dies, tubular dies, and other molds used in continuous casting processes for copper and copper alloys (brass, bronze, and nickel silver), aluminum alloys, cast iron, precious metals, and a variety of other metals.
Graphite can be used with different continuous casting methods (horizontal/vertical) and can be produced in a variety of ingot shapes (including plates, strips, pipes, rods, wire, and contoured shapes).
With a wide range of grades available, we can select the optimal grade for a variety of cast metals and alloys.
We manufactures products from structural brands of graphite, impregnated graphite, antifriction graphite
Graphite has unique properties:
electrical conductivity;
heat resistance (sublimation effect);
poor wettability by many metals;
strength, anomalously increasing with temperature increasing;
possibility to work with dry friction (self-lubrication)
Due to its unique properties, graphite products are used in many industries:
production of ferrous, non-ferrous and precious metals;
engineering;
chemistry, petrochemistry and oil refining;
glass industry;
analytical laboratories;
power engineering and electrical engineering.
