SiC Heating Element with 1500°C Maximum Operating Temperature, Corrosion Resistant and High Thermal Efficiency for Industrial Kilns

SiC Heating Element with 1500°C Maximum Operating Temperature, Corrosion Resistant and High Thermal Efficiency for Industrial Kilns
SiC Heating Element with 1500°C Maximum Operating Temperature, Corrosion Resistant and High Thermal Efficiency for Industrial Kilns SiC Heating Element with 1500°C Maximum Operating Temperature, Corrosion Resistant and High Thermal Efficiency for Industrial Kilns SiC Heating Element with 1500°C Maximum Operating Temperature, Corrosion Resistant and High Thermal Efficiency for Industrial Kilns SiC Heating Element with 1500°C Maximum Operating Temperature, Corrosion Resistant and High Thermal Efficiency for Industrial Kilns

Large Image :  SiC Heating Element with 1500°C Maximum Operating Temperature, Corrosion Resistant and High Thermal Efficiency for Industrial Kilns

Product Details:
Place of Origin: China
Brand Name: ZG
Certification: CE
Model Number: MS
Payment & Shipping Terms:
Minimum Order Quantity: 1PC
Price: 10USD/PC
Packaging Details: Strong wooden box for Global shipping
Delivery Time: 5-8 working days
Payment Terms: L/C,D/A,D/P,T/T,Western Union
Supply Ability: 1000PCS
Contact Now

SiC Heating Element with 1500°C Maximum Operating Temperature, Corrosion Resistant and High Thermal Efficiency for Industrial Kilns

Description
Highlight:

1500°C Maximum Operating Temperature SiC Heating Element

,

Corrosion Resistant Silicon Carbide Heating Element

,

High Thermal Efficiency SiC Heater

SiC Heating Element
Silicon carbide heating elements (SiC heating elements) are tubular non-metallic high-temperature electric heating components manufactured from high-purity green hexagonal silicon carbide through advanced processes including green body forming, high-temperature silicon infiltration, and recrystallization.
Core Performance Specifications
Performance Index Advantageous Scenarios
Maximum operating temperature 1500°C High-temperature sintering and calcination processes
Antioxidant properties Strong (stable in air at 1310℃) Prolonged exposure to high-temperature working environments
Corrosion resistance Resistant to acid and corrosion from CO2/halogens Materials synthesis under complex conditions
Thermal efficiency Heats up quickly, with a surface power density of 3.1-4.0 W/cm² Rapid heating and energy saving requirements
Mechanical strength Flexural strength: 70-90 MPa Thermal shock resistance, impact resistance
Applications
  • Industrial Kilns & Heat Treatment Equipment
  • Laboratory High-Temperature Equipment
  • Powder Metallurgy & Metal Processing
  • Photovoltaic & Semiconductor Industry
  • Environmental Protection & Energy Sector
Customization Services
  • Dimension Customization
  • Resistance Customization
  • Atmosphere Adaptation
Specifications and Models
GD Type (Uniform Diameter)
Outer Diameter (OD): Customizable sizes
Hot Zone Length (HZ) / Cold End Length (CZ): Designed according to requirements
SiC Heating Element with 1500°C Maximum Operating Temperature, Corrosion Resistant and High Thermal Efficiency for Industrial Kilns 0
DC Type (Dumbbell Shape)
Outer Diameter (OD/OD1): Dual-segment diameter design
Overall Length (OL): Adaptable for installation in different furnace types
SiC Heating Element with 1500°C Maximum Operating Temperature, Corrosion Resistant and High Thermal Efficiency for Industrial Kilns 1
Key Technical Parameters
Project Data Application Association
Density 2.5-2.6 g/cm³ Structural strength and thermal conductivity balance
Resistivity 1000-2000 Ω·mm²/m Custom-designed resistor-based temperature control system
Coefficient of linear expansion (20~1500℃) 5×10⁻⁶/℃ Deformation control at high temperatures
Adaptability to different environments/atmospheres Please inquire for details Selection of process gas environment
For specific technical requirements and custom solutions, please contact our engineering team.
